P4 6500 Nits SMD1818 Billboard LED Display With Nationstar Leds

Product Categories

Shenzhen Bako Vision Technology Co., Ltd

Contact Now

Name: P4 6500 Nits SMD1818 Billboard LED Display With Nationstar Leds
Brand: Bako Vision
Price: 1 USD

Brand Name : Bako Vision

Model Number : P4

Certification : CE, RoHs

Place of Origin : China

MOQ : 1sqm

Price : Negotiable

Payment Terms : Western Union, L/C, T/T

Supply Ability : 10,000sqm

Delivery Time : 15 days

Packaging Details : wooden box

Led moudle : 160*160mm

Cabinet size : 960*960mm

Scanning rate : 1920Hz

Driver IC : ICN2038

Brightness : 6500nits

Colors : 281trillions

Contact Now

Energy-saving P4 HD Outdoor Billboard Led Display with Nationstar Leds

P4 Outdoor Billboard Led Display Features:

1. Easy maintenaince: rear access and front access available;

2. Dynamic pictures under direct sunshine;

3. Power saving, due to we use best power supply, best leds, best PCB board, etc;

4. Long lifetime: about 5 years;

P4 Outdoor Billboard Led Display Specifications:

	BOF-B-4
Physical Pitch	4 mm
Pixel Configuration	SMD1818
Pixel Density	62,500 pixels/m²
Module Dimensions (W × H) (mm)	320 × 160
Panel Dimensions (mm)	960 × 960 × 150
NO .of Modules Per Panel (W × H)	3 × 6
Physical Resolution of Module (W × H)	80 × 40
Physical Resolution of Panel (W × H)	240 × 240
Panel Material	Steel / Aluminum
Weight(m²)	65/45
Processing	16 bit
Colours	281 trillion
Contrast Ratio	2,000 : 1
Average Power Consumption	360 W/m²
Max Power Consumption	900 W/ m²
Brightness	≥6500 nits
Refresh Rate	＞1,920 Hz
Horizontal Viewing Angle	160°
Vertical Viewing angle	140°
Expected Lifetime	100, 000 Hrs
Servicing	Rear
IP Rating	IP 65
Operating Temp/Humidity	-20℃-50℃ / 10%-90%
Storage Temp/Humidity	-20℃-50℃ / 10%-90%
Scan Method	1/8 Scan

P4 6500 Nits SMD1818 Billboard LED Display With Nationstar Leds
